Fuel-Gard® 2” Monitor Housings Model HFG

Fuel-Gard® 2” Monitor Housings Model HFG
  • Absorbs free and emulsified water, removes ultra-fine solids and shutdowns the systems flow when hit with a localized slug of water
  • Designed for 174 psi (12 kg/cm²) @ 122ºF (50ºC)
  • Welded carbon steel, stainless steel, aluminium and cast aluminium construction
  • EI 1596 Design & Construction
  • Built to ASME Code, Section VIII, stamped and certified or "CE" marked
Download

Model HFG

Eliminate the need for other water defense devices and receive maximum water removal, solids holding capacity and shutdown protection to assure clean, dry fuel delivery while meeting the latest Energy Institute (EI) specifications.

The new PECOFacet model HFG Horizontal Fuel-Gard monitor housing, equipped with FG model 2" OD monitor cartridges, continually check the entire flow of fuel, for water or solids contamination. By performing three jobs, the FG monitors assure clean, dry fuel. They absorb free and emulsified water, remove ultra-fine solids even when surfactants and fuel additives are present, and shut down the systems flow when hit with a localized slug of water. They are designed to flow from the outside to inside at a rate of 1 GPM (3.79 lpm) per inch of length.

Standard Design Features

  • Welded carbon steel, stainless steel, aluminum and cast aluminum construction
  • EI 1596 Design & Construction
  • Built to ASME Code, Section VIII, stamped and certified or "CE" marked
  • Design pressure: 174 psi (12 kg/cm²) @ 122ºF (50ºC)
  • Spider support plate
